HIKVISION DS-1100KI User Manual

DS-1100KI Network Keyboard User Manual
66
keys on the keyboard to enter the text box below. Finally, click Add to add the current macro command.
 Up to 128 macro commands can be added.
 Max. 6 numerals can be included in a macro command.
 The local decoding and live view operation is not supported currently.
Figure 4. 56 Adding Macro
Viewing Macro
The added Macro commands are listed on the Macro Settings-Macro List interface.
You can click to view each macro command.
Figure 4. 57 Viewing Macro
Running Macro
Select a command from the list and click to run the command, or directly click Num + MAC keys on the
interface to call the macro command.

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
