HIKVISION DS-K1TA70MI-T User Manual

Figure 4-1 Terminal Diagram
The descripons of the terminals are as follows:
Table 4-1 Terminal
Descripons
Group No. Funcon Color Name Descripon
Group A A1 Power Input Red +12 V 12 VDC Power
Supply
A2 Black GND Ground
Group B B1 Alarm Input Yellow/Blue IN1 Alarm Input 1
B2 Yellow/Black GND Ground
B3 Yellow/Orange IN2 Alarm Input 2
Face Recognion Terminal User Manual
11

HIKVISION DS-K1TA70MI-T Specifications

General

Brand	HIKVISION
Model	DS-K1TA70MI-T
Category	IP Access Controllers
Language	English
