Caregiver Siderail Controls
Progressa™ Bed User Manual (171528 REV 1) 17
Siderail Controls Location
The Point-of-Care® Siderail controls are located on the outboard side of the siderails.
Lockout Controls
The Lockout controls are located on the intermediate
siderail caregiver control panel. The Lockout controls
disable the bed articulating functions. The Lockout controls
are used when it is necessary to prevent bed movement.
Emergency CPR will not be locked out. If CPR is activated,
any controls that are locked out will become unlocked.
Follow facility protocol for lock outs to reduce the likelihood
of unauthorized use of the bed controls.
WARNING:
Lock out all articulation controls when traction equipment is installed. Failure to do so could cause
patient injury.
To Activate
• At the same time press the Lockout control and the function control.
– A single beep sounds and the locked function indicator will stay on. Both patient and
caregiver controls are locked out.
– If the lock out procedure is done incorrectly, the bed will beep three times and a screen will
show on the GCI to show the correct procedure.
• The knee lockout will lock out the foot control. The foot Up/Down lockout will lock out the knee
control.
• The bed up down lockout will lock out Trendelenburg and Reverse Trendelenburg.
• Any lockout will also lock out all chair positions and bed flat.
To Deactivate
• Disable any lockout by simultaneously pressing the Lockout control and the respective
function control. A single beep will sound when the lockout is deactivated.
Bed Up/Down
The Bed Up/Down controls are located on the head-end siderails and on the intermediate
siderails. They adjust the height of the bed from a low position for patient exit to a high
position for examination. To lock out a control, see “Lockout Controls” on page 17.
WARNING:
Lowering the bed may cause linens, drainage bags, and other equipment to come in
contact with the floor. Follow facility protocol if they touch the floor. Injury could occur.
