Bed Frame Features
50 Progressa™ Bed User Manual (171528 REV 1)
IV Pole Sockets
The Progressa™ Bed comes with four standard IV
sockets. Two are located at the head end and two are
located behind the footboard at the corners of the foot end.
WARNING:
Remove all equipment from the foot-end equipment
sockets before you put the bed in the chair position.
Injury could occur.
WARNING:
Make sure there is sufficient room at the head-end of
the bed for equipment in the sockets when you raise
the bed or go in to the Trendelendburg/Reverse
Trendelenburg positions. Injury or equipment damage
could occur.
Fracture Frame Sockets
WARNING:
Caregiver to evaluate patients for entrapment and asphyxiation when using traction equipment.
WARNING:
Follow facility protocol for lockouts of bed controls when traction equipment is installed. Failure to
do so could cause injury.
There are four locations for the traction equipment to install—
two at the head end, and one on each side of the bed near the
thigh section. Make sure to use the appropriate adapter for the
traction equipment according to the manufacturers instructions.
Permanent IV Pole Option
The Permanent IV Pole option consists of one IV pole that supports up to
two IV pumps plus bags. The IV pole is attached to the frame near one of
the corners of the headboard.
Up to 40 lbs. (18.1 kg) of total weight can be supported per pole.
A permanent IV pole will use one of the removable IV pole sockets on the
head-end of the bed.
To Raise
1. Lift the IV pole from its stored position from behind the headboard.
2. Make sure that the pole drops and locks into position.
3. Hold the bottom section.
4. Raise the middle and upper sections of the pole until they click and lock into place. The pole is
ready for use.
Head
End
Foot
End
Head
End
