Accessories
68 Progressa™ Bed User Manual (171528 REV 1)
Accessories
Accessories may be added or removed at the point of patient care by a caregiver without the use of
tools. Accessories are interchangeable within a product configuration.
Table 1. Accessories
Infusion Support System (P158A)
The Infusion Support System (ISS) consists of a movable and adjustable IV pole. The pole supports IV
pumps or bags in a vertical orientation and raises or lowers the pumps or bags with respect to the bed
frame.
The head end of the bed has attaching points for two mobile Infusion Support Systems. Each Infusion
Support System can support one infusion pump plus two liters of intravenous solution.
The ISS pole installs in to one of the IV pole sockets with the P7515A adapter kit.
The P158A ISS IV pole is a removable, two section telescopic pole that installs at the head end of the
bed into an adapter that snaps into the receiver holes. The IV pole can hold 20 lb (9 kg).
CAUTION:
ISS Pole safe working load is 20 lbs. (9 kg). Exceeding the safe working load can cause
equipment damage.
CAUTION:
Do not mount infusion pumps on the lower section of an IV pole. Interference with head section
articulation could result.
CAUTION:
When lowering the upper section of an IV pole, always grasp and hold the upper section of the
pole before pulling the release knob.
Removable IV Pole (P7510A)
WARNING:
Exceeding the safe working load can cause injury or equipment damage.
Product Number Description
Usable Equipment Sockets
Head-End Foot-End
P158A Infusion Support System
X
a
a. Requires adapter.
P7515A ISS pole adapter kit X
P7510A Progressa™ Removable IV Pole X
P2217A Removable Telescopic IV Pole
X
a
X
P7511A Progressa™ Permanent IV Pole X
P7514A IV Pole adapter kit (for P2217 IV pole) X
P7507A01/02/03/04 Caregiver Pendant See “Caregiver Pendant Con-
trols” on page 26.
