Accessories
Progressa™ Bed User Manual (171528 REV 1) 69
The IV pole is a removable, three section, telescopic pole that installs at the head end of the bed, in
the hole provided. A permanently attached adapter is required. The IV pole can hold 40 lb (18 kg).
To install the standard IV pole, insert and rotate a quarter-turn clockwise. Removal is opposite of
installation.
CAUTION:
When lowering the upper section of an IV pole, always grasp and hold the upper section of the
pole before pulling the release knob.
Added height recommended for gravity drain applications.
Removable Telescopic IV Pole (P2217A)
WARNING:
Exceeding the safe working load can cause injury or equipment damage.
The P2217A IV pole is a removable, two section telescopic pole that installs at any of the four corners
of the bed, with adapters for the holes at the head end of the bed. The IV pole can hold 25 lb (11kg).
To install the P2217A IV pole, insert and rotate a quarter-turn clockwise. Removal is opposite of
installation.
Vertical Oxygen Tank Holder
The oxygen tank holders are located in the head end corners of the upper
frame. The blue sleeve holds a steel tank and the gray sleeve holds an
aluminum tank. Each oxygen tank holder accommodates one D-size or E-
size oxygen tank with a regulator.
If the optional oxygen tank holders are not installed, then this space will be
covered.
WARNING:
Each vertical oxygen tank holder safe working load is 30 lbs. (13.6 kg). Exceeding the safe
working load can cause injury or equipment damage.
To Install:
Install the oxygen tank in the holder. Make sure the support cage completely
lowers when you install the tank.
To Remove:
Lift the tank out of the holder.
NOTE:
A blue insert sleeve is required for steel oxygen tanks. A grey insert
sleeve is required for aluminum oxygen tanks.
