9.2 General Specifications
────────────────────────────────────────────────────
1
2
3
4
5
6
7
9
11
12
13
14
15
Display
Fluorescent tube display (digital display)
Monitor function
Output voltage / current
Monitor cycle
2Hzorfaster
Ambient operating conditions
0to40
℃
(32 to 104
ﾟ
F), 80%RH max. (no condensation)
Ambient storage conditions
-10 to 50
℃
(14 to 122
ﾟ
F), 90%RH max. (no condensation)
Operating temperature and
humidity for guaranteed
accuracy
Guaranteed accuracy
period
23
℃±
5
℃
(73
ﾟ
F
±
9
ﾟ
F), 80%RH max. (no condensation)
after 5 minutes minimum warm-up
For 1 year
Product warranty period
3 years
Operating Environment
Indoors, Pollution Degree 2, < 2000 mASL (6562 feet)
Power supply
120 VAC (3158-01) / 220 VAC (3158-03)
230 VAC (3158-04) / 240 VAC (3158-05)
(Voltage fluctuations of 10% from the rated supply voltage are
taken into account.)
Rated power frequency
50 to 60 Hz
Dielectric strength
1.39 kVAC, 10 mA, 1 minute between power supply and frame
Maximum rated power
800 VA
Dimensions
Approx. 320W x 155H x 263D mm (12.60"W x 6.10"H x
10.73"D) (excluding projections)
Mass
Approx. 16 kg (564.4 oz.) (3158-01)
Approx. 18 kg (634.9 oz.) (3158-03, -04, -05)
Fuse
250VT8AL (3158-01), 250VT4AL (3158-03, -04, -05)
Accessories
9615 H.V. TEST LEAD (high voltage side and return, 1 each)
Power cord
Instruction manual
Spare fuse
Options
9613 REMOTE CONTROL BOX (SINGLE)
9614 REMOTE CONTROL BOX (DUAL)
9267 SAFETY TEST DATA MANAGEMENT SOFTWARE
9637 RS-232C CABLE (9pin-9pin/ 1.8 m)
9638 RS-232C CABLE (9pin-25pin/ 1.8 m)
Standard Applying
EMC: EN61326 CLASS A
Safety: EN61010
