8.2 Specifications
100
8.2 Specifications
RS-232C Specifications
Transfer method
Communications : Full duplex
Synchronization : Start-stop synchronization
Baud rate
9600 bps/ 19200 bps/ 38400 bps
Data length
8 bit
Parity
none
Stop bit
1 bit
Message terminator
(delimiter)
Receiving : CR+LF, CR
Transmitting : CR+LF
Flow control
none
Electrical specification
Input voltage levels 5 to 15 V: ON, -15 to -5 V: OFF
Output voltage levels 5 to 9 V: ON, -9 to -5 V: OFF
Connector
RS-232C Interface Connector Pinout
(Male 9-pin D-sub, with #4-40 attachment screws)
The I/O connector is a DTE (Data Terminal Equipment) configuration
Recommended cables:
• Model 9637 RS-232C CABLE (for PC/AT-compatibles)
• Model 9638 RS-232C CABLE (for PC98-series)
See " Attaching the Connector" (p.102).
LAN Specifications
Applicable standard
IEEE802.3
Transmission method
10BASE-T / 100BASE-TX automatic recognition
Half/Full Duplex Auto MDI-X
Protocol
TCP/IP
Connector
RJ-45
Cable length
Up to 30 m
Communication description
Setting and measured value acquisition by using communications com-
mands
