8.6 Message Reference
160
Model BT3562 and BT3563 Battery Hitester accept all of the commands sup-
ported by the HIOKI 3560 AC m
 Hitester.
However the following differences result from the functional differences.
Comparator Tables
Up to 30 comparator settings can be saved with the Model 3560. The settings of
each table can be changed directly by specifying the table number.
With this instrument, up to 126 measurement configurations (including compara-
tor settings) can be saved (Panel Save). Settings for each configuration cannot
be set directly. To recall saved configuration settings, specify the table (panel)
number and execute Panel Load. A table number does not need to be specified
for comparator settings.
Comparator Operations
Model 3560 judges resistance and voltage measurements together as PASS/
FAIL.
This instrument judges resistance and voltage independently. Also, when the
Comparator function is enabled (ON), auto-ranging is disabled (OFF).
Voltage Limiter
This instrument does not include a voltage limiter function (limiting open-terminal
voltage to 20 mV). This instrument’s open-terminal voltage is maximum 25 V
(peak).
The voltage will drop to several mV within 100 s of the measurement leads
being connected to the target.
Note that a maximum 4 V peak will be applied when the test object resistance
exceeds the range's measurement range by a significant margin.
Sense Line Disconnect Detection
The sense line disconnect detection function cannot be switched on/off with this
instrument. Detection is always enabled.
Resistance Value Digits with FAST Sampling
When FAST sampling is enabled on Model 3560, the number of resistance mea-
surement digits is decreased from five to four.
With this instrument, measurement values are always five digits (31000 counts)
regardless of sampling rate.
Voltage Measurement
Model 3560 provides 5 and 50 V ranges, with five-digit (50000 count) measure-
ment values.
The instrument offers 6 V, 60 V, 100 V
*1
, and 300 V
*2
ranges and generates
measured values that have one more digit (for a total of six digits) than the Model
3560.
*1: The 100 V range is only available on the Model BT3562A.
*2: The 300 V range is only available on the Model BT3563A, BT3563, or
BT3563-01.
Command Compatibility with the Model 3560 AC m HiTESTER
HIOKI BT3562A981-09
