1.2 Features
10
The four-terminal AC method measures resistance and DC voltage simultane-
ously, so battery internal resistance and emf are measured and judged at once.
Resistance measurement resolution of 1  or 0.1  and voltage measure-
ment resolution of 10 V. The voltage measurement accuracy of ±0.01% of
reading is achieved.
Simultaneous resistance and voltage measurements can be performed as fast
as once every 20 ms.
(Response time of approx. 10 ms + sampling time of approx. 8 ms)
The Model BT3563 supports measurement of high-voltage batteries of up to 300 V.
(the Model BT3561A, BT3562, and BT3562-01 supports measurement of up to
60 V) (the Model BT3562A supports measurement of up to 100 V)
Resistance and voltage measurement values are judged in three categories (Hi,
IN and Lo), with results clearly displayed. A comparator judgment beeper also
provides distinct sounds to indicate pass/fail judgments and to facilitate correct
recognition of judgment results.
Maximum, minimum and average measurement values, standard deviation, pro-
cess capability indices and other values can be automatically calculated for
applications such as production management. Calculation results can also be
applied as comparator setting values.
The instrument includes a Memory function and storage capacity for up to 400
pairs of measurement values. When making many sequential measurements at
high speed and sending the measured values to a PC after each measurement,
the time to switch test objects can become unsatisfactorily long. The Memory
function can avoid the slow-down by sending stored measurements in batches
during idle times.
EXT I/O and RS-232C interfaces are equipped as standard, supporting transfer
rates up to 38,400 bps.
• Model BT3562-01 and BT3563-01 also supports GP-IB and analog output.
• Model BT3561A, BT3562A, and BT3563A also supports LAN and analog out-
put.
Connect the printer to print measurement values and statistical calculation
results.
1.2 Features
Simultaneously Measures Battery Internal Resistance and Volt-
age
High-Precision Measurements
High-Speed Measurements
High-voltage measurement
Comparator Functions
Statistical Calculation Functions
Measurement Value Memory Function
EXT I/O Interface
Printing Measurement Values and Statistical Results
HIOKI BT3562A981-09
