4.2 Trigger Function
60
Specify the delay from the moment a trigger is applied to the start of measurement. By using this function,
even when a trigger is applied immediately after connecting a test object, the start of measurement can be
delayed to allow sufficient time for the measurement value to stabilize. Trigger delay can be set with 1 ms res-
olution from 0.000 to 9.999 seconds.
Trigger Delay Settings
1
(The SHIFT indicator lights up.)
The Trigger Delay setting display appears.
2
Select ON.
3
The numerals indicating the trigger delay blink.
4
Set the trigger delay.
5
Applies setting and returns to the Measurement display.
To cancel the settings:
SHIFT key
(Main Display)
(Sub Display)
The current setting blinks.
(Sub Display)
(Sub Display)
Or numeric keypads
Disabling the Trigger Delay Function
1
(The SHIFT indicator lights up.)
The Trigger Delay setting display appears.
2
Select OFF.
3
The Trigger Delay is disabled.
(Sub Display)
To Next Page
