9.2 Accuracy
186
RS-232C Communications settings: Data length: 8 bit, stop bit: 1 bit, parity: none
Baud rate: 9600 bps/ 19200 bps/ 38400 bps
Flow control: none
Printer Output to printer via RS-232C (multi-use)
Communications settings: Data length: 8 bit, stop bit: 1 bit, parity: none
Baud rate: 9600 bps
LAN
(BT3561A, BT3562A, and
BT3563A only)
The settings can be changed by accessing the instrument using a web
browser.
Applicable standard: IEEE802.3
Transmission method: 10BASE-T/ 100BASE-TX automatic recognition,
Half/Full Duplex, Auto MDI-X
Protocol: TCP/IP
Connector: RJ-45
Maximum cable length: 30 m
Communication description: Setting and measured value acquisition by
using communications commands
Settings: IP address, subnet mask, default gateway
Communication command port number: 11 to
65535 (excluding 80)
Default setting: IP address: 192.168.1.1
Subnet mask: 255.255.0.0
Default gateway: 0.0.0.0 (unused)
Communication command port number: 23
GP-IB
(-01 only)
Applicable GP-IB Standards: IEEE488.2
Address: 0 to 30
Delimiter: LF/ CR+LF
Analog output
(BT3561A, BT3562A,
BT3562-01, BT3563A and
BT3563-01 only)
Output: Resistance measured value (display value)
Output voltage: 0 V DC (equivalent to 0 counts) to 3.1 V (equivalent
to 31000 counts)
Output impedance: 1 k
Conversion method: D/A converter
No. of bits: 12 or more
Output accuracy: Resistance measurement accuracy ±0.2% of full scale
(temperature coefficient ±0.02% of full scale/°C)
Conditions of accuracy guarantee:
Temperature and humidity range:
23 ± 5°C (73 ± 9°F), 80% RH or less (non-condensating)
Warm-up time of at least 30 min.
Response time: Resistance measurement response time + sampling time
+ 1 ms
External Interfaces
9.2 Accuracy
Guaranteed Accuracy Conditions
Temperature and humidity
range for guaranteed
accuracy
23 ± 5°C (73 ± 9°F), 80% RH or less (non-condensating)
Zero-adjustment After zero adjustment
