8.2 Specifications
97
8
Chapter 8 RS-232C/GP-IB Interfaces
Interface Functions
Operating Code: ASCII codes
8.2 Specifications
RS-232C Specifications
Transfer method
Communications : Full duplex
Synchronization : Start-stop synchronization
Baud rate
9600 bps/ 19200 bps/ 38400 bps
Data length
8 bits
Parity
none
Stop bit
1 bit
Message terminator
(delimiter)
Receiving : CR+LF, CR
Transmitting : CR+LF
Flow control
none
Electrical specification
Input voltage levels 5 to 15 V: ON, -15 to -5 V: OFF
Output voltage levels 5 to 9 V: ON, -9 to -5 V: OFF
Connector
RS-232C Interface Connector Pinout
(Male 9-pin D-sub, with #4-40 attachment screws)
The I/O connector is a DTE (Data Terminal Equipment) configuration
Recommended cables:
• Model 9637 RS-232C Cable (for PC/AT-compatibles)
• Model 9638 RS-232C Cable (for PC98-series)
See " Attaching the Connector" ( p.98).
GP-IB Specifications
SH1 All Source Handshake functions are supported.
AH1 All Acceptor Handshake functions are supported.
T6 Basic talker functions are supported. Serial poll function are sup-
ported. No talk-only mode. The talker cancel function with MLA
(My Listen Address) is supported.
L4 Basic listener functions are supported. No listen-only mode. The
listener cancel function with MTA (My Talk Address) is supported.
SR1 All Service Request functions are supported.
RL1 All Remote/Local functions are supported.
PP0 No Parallel Poll function.
DC1 All Device Clear functions are supported.
DT1 All Device Trigger functions are supported.
C0 No Controller functions are supported.
HIOKI BT3564A961-02
