3.3 Selecting Measurement Mode
26
Select the measurement mode from V (both resistance and voltage measurement),  (resistance measure-
ment only), or V (voltage measurement only).
3.3 Selecting Measurement Mode
1
Confirm the SHIFT lamp is not lit.
If this is lit, press the SHIFT key to turn it off.
2
Switches the displayed measurement mode.
Each key-press switches the measurement mode.
SHIFT not lit
V mode
(Resistance and Voltage measurement) measurement)
 mode
(Resistance measurement)
V mode
(Voltage measurement)
“” or “m” lit
“V” indicates the
V mode is selected
The fastest measurements are provided by selecting the  or V mode when
measuring resistance or voltage, respectively.
See "Sampling time" ( p.166).
