3.4 Setting Measurement Range
27
3
Chapter 3 Measurement
This section describes how to set the measurement range for resistance or voltage measurement. For resis-
tance measurement, you can select from seven ranges from 3 m to 3000 . For voltage measurement, you
can select from three ranges from 10 V to 1000 V. There is also an auto-range function, which determines the
optimal range automatically.
3.4 Setting Measurement Range
Resistance measurement range
1
Select the resistance measurement range.
The position of the decimal point and unit of measurement on the display will
be switched according to the selected range.
lit
m lit
When the 3 range is selected
When the 300 m
range is
selected
Increase the resistance measurement range.
Decrease the resistance measurement range.
Pressing the up or down keys while in auto-range mode will cancel auto-ranging,
leaving the current measurement range as the manually set range.
To Next Page
