3.7 Displaying Measurement Results
37
3
Chapter 3 Measurement
Overflow is indicated by “OF” or “-OF” on the display, caused by one of the fol-
lowing:
Overflow Display
Display Condition
OF
• The measured value exceeds the limit of the current
measurement range
• The test object impedance exceeds the input level.
• When the result of relative value calculation is larger
than +99.999%.
-OF
• The measured value is below the limit of the current
measurement range
• The test object impedance exceeds the input level (in
the negative direction).
• When the result of relative value calculation is smaller
than -99.999%.
HIOKI BT3564A961-02
