9.2 Basic Specifications
166
9.2 Basic Specifications
Measurement items Measurement items: resistance and voltage
Resistance measurement method: AC four-terminal method
Resistance measurement current frequency: 1 kHz ±0.2 Hz
Measurable range Resistance measurement range: 0  to 3.1 k (minimum resolution 0.1 )
Voltage measurement range: 0 V DC to ±999.999 V DC (minimum resolution
10 V)
Voltage displaying range: ±1100.00 V
Measurement range Resistance measurement: 3 m/30 m/300 m/3 /30 /300 /3000 ,
7 ranges
Voltage measurement: 10 V/100 V/1000 V, 3 ranges
Auto-range function: ON/OFF (applies to both resistance and voltage mea-
surement.)
DC input resistance 5 M
Open-terminal voltage 25 V peak
Measurement modes
V mode: Measures resistance and voltage simultaneously
mode: Measures resistance only
V mode: Measures voltage only
Maximum input voltage ±1000 V DC
Maximum rated voltage
to earth
1000 V DC Anticipated transient overvoltage: 1500 V
Response time Measurement response time: Approximately 700 ms
The time from the moment the probes contact the test object in the open state
until the signal stabilizes within the measurement accuracy in the internal
measurement circuit (analog response time)
Sampling time Sampling rate: FAST/MEDIUM/SLOW, 3 levels
Tolerance for SLOW sampling is ±5 ms, and ±1 ms for other sampling rates
Values within parentheses are line frequency settings
Total measurement time Overall time required for measurement: Response time + sampling time
Sampling FAST MEDIUM SLOW
V (50 Hz)
(60 Hz)
28 ms 88 ms
74 ms
384 ms
359 ms
 (50 Hz)
(60 Hz)
12 ms 42 ms
35 ms
276 ms
253 ms
V (50Hz)
(60Hz)
16 ms 46 ms
39 ms
281 ms
257 ms
