6.1 Connecting the Printer
87
6
Chapter 6 Printing
Before connecting the printer
Recommended printer
The requirements for a printer to be connected to the instrument are as follows.
Confirm compatibility and make the appropriate settings on the printer before
connecting it to the instrument.
• Interface ................................ RS-232C
• Characters per line................ At least 45
• Communication speed .......... 9600 bps
• Data bits................................ 8
• Parity..................................... none
• Stop bits ................................ 1
• Flow control........................... none
• Control codes ........................ Capable of directly printing plain text
Printing Chapter 6
6.1 Connecting the Printer
Because electric shock and instrument damage hazards are present, always fol-
low the steps below when connecting the printer.
• Always turn off the instrument and the printer before connecting.
• A serious hazard can occur if a wire becomes dislocated and contacts another
conductor during operation. Make certain connections are secure.
• As much as possible, avoid printing in hot and humid environments. Other-
wise, printer life may be severely shortened.
• Use only compatible recording paper in the printer. Using non-specified paper
may not only result in faulty printing, but printing may become impossible.
• If the recording paper is skewed on the roller, paper jams may result.
The optional printer model 9670 is no longer available. Their model 9670 printers
can still use.
