9.4 Functions
Zero-adjustment function Enable or cancel zero-adjustment
Zero-adjustment setting: ON/OFF
Cancel zero-adjustment: Turn off the zero-adjustment to clear all zero-adjust-
ment data.
Zero-adjustment range
Resistance measurement: -1000 to 1000 counts
Voltage measurement: -1000 to 1000 counts
Self calibration Calibration mode: AUTO/MANUAL
AUTO: executes automatically once every 30 minutes
MANUAL: executes manually by EXT I/O signal or remote command
* When sampling is set to SLOW, the instrument performs self-calibration
before each measurement.
Trigger function Trigger source: Internal/External
Delay function Delay setting: ON/OFF
Delay time: 0 to 9.999 sec
Averaging function Averaging setting: ON/OFF
No. of samples to average: 2 to 16 times
Comparator function Comparator function setting: ON/OFF
Comparator setting
Comparator mode: HIGH, LOW/REF, %
Upper and lower limit value: 0 to 99999 (Resistance)/0 to 999999 (Voltage)
Reference value: 0 to 99999 (Resistance)/0 to 999999 (Voltage)
%: 0.000% to 99.999% (percentage range setting applies to both positive
and negative values)
Comparator judgment beeper mode: OFF/HIGH, LOW/IN/ALL
Operating mode: AUTO/MANUAL
* Measurement value or statistical 3 (population standard deviation
× 3)
can be set as upper/lower limit or reference values.
Decision
Judgment result: Hi/IN/Lo (resistance and voltage judged independently)
PASS/FAIL judgement Calculates the logical AND of resistance and voltage
judgment results and outputs a PASS/FAIL judgment (EXT I/O output).
Measurement fault value judgments:
OF; Hi judgment
-OF; Lo judgment
Measurement fault; Not judged (no judgment result)
Statistical calculation
function
Statistical calculation setting: ON/OFF/Clear
Auto-clear after printing statistical data
Calculations: Total data counts, valid data counts, maximum, minimum,
average, standard deviation, population standard deviation and process
capability indices (Cp and CpK)
Calculations trigger: Statistical calculation of measured values initiated by
EXT I/O signals, key or remote command
