1.2 Features
8
Simultaneously Measures Battery Internal Resistance and
Voltage
The four-terminal AC method measures resistance and DC voltage simultane-
ously, so battery internal resistance and emf are measured and judged at once.
High-precision Measurements
The instrument provides high-resolution resistance (0.1 ) and voltage mea-
surements (10 V). High precision (
± 0.01% rdg.) ensures accurate voltage
measurements.
High-speed Measurements
Simultaneous resistance and voltage measurements can be performed as fast
as once every 28 ms.
(Sampling time of approx. 28 ms)
High-voltage measurement
The Model BT3564 supports measurement of high-voltage batteries of up to
1000 V.
Comparator Functions
Resistance and voltage measurement values are judged in three categories (Hi,
IN, and Lo), with results clearly displayed. A comparator judgment beeper also
provides distinct sounds to indicate pass/fail judgments and to facilitate correct
recognition of judgment results.
Statistical Calculation Functions
Maximum, minimum, and average of the measurement values, standard devia-
tion, process capability indices and other values can be automatically calculated
for applications such as production management. Calculation results can also be
applied as comparator setting values.
Measurement Value Memory Function
The instrument includes a Memory function and storage capacity for up to 400
pairs of measurement values. When making many sequential measurements at
high speed and sending the measured values to a PC after each measurement,
the time to switch test objects can become unsatisfactorily long. The Memory
function can avoid the slow-down by sending stored measurements in batches
during idle times.
EXT I/O Interface
EXT I/O and RS-232C interfaces are equipped as standard, supporting transfer
rates up to 38,400 bps. Model BT3564 also supports GP-IB and analog output.
Printing Measurement Values and Statistical Results
Connect the printer to print measurement values and statistical calculation
results.
