1.4 Menu Display Sequence (SHIFT > ENTER)
13
1
Chapter 1 Overview
Various auxiliary settings can be performed from the menu item displays.
1.4 Menu Display Sequence (SHIFT > ENTER)
ERR Output Selection
display (
 p.80)
Zero-Adjustment Clear
display (
 p.34)
Interface Selection
display (
 p.100)
Self-Calibration setting
display (
 p.69)
Measurement Value Output
function setting display
( p.70)
Key Beeper setting
display (
 p.71)
Line Frequency set-
ting display
(
 p.20)
(SHIFT Lamp lit)
The Menu display appears.
(Main display)
The up/down RANGE key changes the setting
shown on the sub display.
Pressing this key returns to the
previous item display.
EOM-signal setup dis-
play (
 p.80)
Configuring the Absolute
Value Judgment display
( p.53)
Reset display
(
 p.72)
Settings on the menu item displays are applied and saved internally when
changed.
