3.4 Setting Measurement Range
28
Voltage measurement range
1
(The SHIFT indicator lights up.)
Select the voltage measurement range.
V lit
V lit
When the 100 V range is selected
When the 10 V range is selected
Increase the voltage measurement range.
Decrease the voltage measurement range.
V lit
When the 1000 V range is selected
Increase the voltage measurement range.
Decrease the voltage measurement range.
