8.6 Message Reference
153
8
Chapter 8 RS-232C/GP-IB Interfaces
Compatibility of each of the Model 3560 commands is described below with details of the functional differ-
ences with the instrument.
For the instrument, the command header is set to off when the instrument is turned on or reset (including
*RST).
Message ([ ] = optional) Data Contents
( ) = response data
Differences
Model BT3564 Model 3560
Standard Commands
IDN?
<Manufacturer's
name>,<Model name>,0,
<Software version>
Model name in response data:
BT3564
Model name in response data:
3560
OPC
OPC?
1
RST
Initialization contents
Measurement mode:
V mode (Resistance and
voltage measurement)
Header: OFF
Power supply frequency: AUTO
Zero-adjust value: Initialized to 0
Initialization contents
Measurement mode: Resis-
tance measurement mode
Header: ON
Power supply frequency: 50 Hz
Zero-adjust value: Not initialized
SRE
SRE?
0 to 255 (NR1)
STB?
0 to 255 (NR1)
TRG
TST?
0 to 3 (NR1) Response data
bit2: -, bit1: EEP-ROM,
bit0: RAM
Response data
bit2: EEP-ROM, bit1: RAM,
bit0: ROM
WAI
Device-Specific Commands
:MODe
:MODe?
R/ RV
:RRANge
:RRANge?
0 to 3.1E+3
3E-3 to 3E+3
:VRANge
:VRANge?
-1000 to 1000
10E+0/100E+0/1E+3
Voltage range: -1000 to 1000 V
10 V/100 V/1000 V ranges are
supported.
Voltage range: -50 to 50
Response: 5E+0/ 50E+0
:AUTorange
:AUTorange?
1/ 0/ ON/ OFF
ON/ OFF
Setting is not possible when the
comparator is enabled (when
the comparator is set to ON,
auto-ranging is turned OFF).
Setting is possible even when
the comparator is enabled
(ON).
:ADJust?
0/ 1 Performs a measurement to
generate the zero-adjustment
value.
Zero-adjustment range:
1000 counts
Applies the currently displayed
value as the zero-adjustment
value.
Zero-adjustment range:
2400 counts
:SAMPle
:SAMPle?
FAST/ MEDium/ SLOW
:COMParator
:COMParator?
0 to 30 Range of panel numbers:
Turns Off when the panel num-
ber is 0, and turns On when the
panel number is 1 to 30
Response:
Returns 0 when the compara-
tor is disabled (OFF), and 1
when enabled (ON)
Range of Comparator Num-
bers: 0 to 30
Response:
Returns the response number
To Next Page
