8.6 Message Reference
156
Measurement Value Formats (compatible command with Model 3560)
For the commands that acquire measurement values
(
:MEASure:BATTery?, :MEASure:RESistance? and
:MEASure:VOLTage?), the response formats are as follows.
Measured resistance value
Measured voltage value
• The positive sign for measured voltage values is returned as a space charac-
ter.
• The number of displayed digits is unaffected by sampling rate.
• The response will take the form of
±*.*****E+3 at voltages of -1000 V or
less and 1000 V or greater.
Reference: Model 3560 Measurement Value Formats
Measured resistance value
Measured voltage value
Measurement Range Measured Value
3 m
 *.****E-3
30 m
 **.***E-3
300 m
 ***.**E-3
3
 *.****E+0
30
 **.***E+0
300
 ***.**E+0
3000
 *.****E+3
± OF 1.0000E+8
Measurement Fault 1.0000E+9
Measurement Range Measured Value
10 V
±*.*****E+0
100 V
±**.****E+0
1000 V
±***.***E+0
± OF ±1.0000E+8
Measurement Fault 1.0000E+9
Measurement Range FAST MEDIUM/ SLOW
30 m
 ***.*E-3 ***.**E-3
300 m
 ***.*E-3 ***.**E-3
3
 *.***E+0 *.****E+0
30
 **.**E+0 **.***E+0
300
 ***.*E+0 ***.**E+0
3000
 *.***E+3 *.****E+3
± OF 1.0000E+8 1.0000E+8
Measurement Fault 1.0000E+9 1.0000E+9
Measurement Range All sampling rates
5 V
±*.****E+0
50 V
±**.***E+0
± OF ±1.0000E+8
Measurement Fault 1.0000E+9
