● Editing Standard Character Patterns 5-24
(1) Overview
¡ Character patterns of printing are edited by the dot.
¡ Subject standard characters are 90 characters of alphabetical characters,
numbers and symbols.
¡ Operations of pattern editing are the same as the "Create user pattern"
function.
¡ The characters whose patterns have been changed will be displayed in blue
on keyboard.
¡ Create the character patterns while printing with the user pattern: Once the
pattern design has been established, use the "Edit standard pattern" function.
(2) Operating procedure
¡ A pattern of character size 7 x 10, character "7" is edited.
5.6 Editing Standard Character Patterns
Maintenance
Auxiliary
function
Show fault
Menu
Operation
management
Environment
setup menu
1
Verify that the printer is in "Stop" state.
Choose Auxiliary function from the menu.
The "Auxiliary function menu" screen then opens.
2011.07.07 12:45
Manage messages
Create user
pattern
Calibrate touch
screen coordinates
Aux. function menu
Back
Manual
Status: Stop Com=0
Start
up
Shut
down
Comm
On/Off
Copy data
Select Languages
Edit Standard
pattern
Create Messages
2
Press Edit Standard pattern .
Edit standard pattern
2011.07.07 12:45
Char. size ［２］(1:5×5 2:5×8 3:7×10 4:12×16 5:18×24 6:24×32)
Pattern
（ ）
Select
Back
Status: Stop Com=0
↓
↑
Incre-
ment
Decre-
ment
