● Transmission Sequences 6-27
No.
1
2
3
4
5
6
7
ESC Header 20H
Character Character
Pattern data array
size code
6.4.5 User Pattern Character Transmission
6.4.5-1 Text
¡ When the number of communication bytes is set to "1" for communication
environment setup purposes.
Character code
¡ When the number of communication bytes is set to "2" for communication environment
setup purposes
ESC Header 20H
Character High-order Low-order
Pattern data array
size byte byte
6.4.5-2 Character size
The character size is represented by the codes shown in the following table.
Character size code table
Type
5×5
5×8 (5×7)
7×10
9×8 (9×7)
12×16
18×24
24×32
Character
size code
30H
31H
32H
32H
33H
34H
35H
Remarks
（*1）
（*1）
(*1) Sizes No. 3 (7 x 10) and No. 4 (9 x 8) use the same character size code. However,
either of them may be automatically selected in accordance with the "Character size
menu 2" setting in the user environment setup screen.
6.4.5-3 Pattern data
(1) Pattern data length
The pattern data length per character varies with the character size as indicated
below.
Character size
5×5
5×8 (5×7)
7×10
9×8 (9×7)
12×16
18×24
24×32
Pattern data length (bytes)
8
8
16
16
32
72
128
