● Transmission Sequences 6-29
¡
For pattern data composition purposes, the data is arranged in successive order,
beginning from the bottom left, from bottom to top and from left to right.
b）Pattern data example
a）For a character size of 5 x 5
Rotated 90 degrees counterclockwise
Inter-character space data area
●
● ●
●
●
●
● ● ●
●
●
●
First byte
Second byte
Third byte
4
byte
5
byte
6
byte
7
byte
8
byte
●
● ●
●
●
●
Unusable area
Removal of the first byte
0 0 0 0 0 1 1 1 = 07H
2
7
2
0
Composition order 1 2 3 4 5 6 7 8
Pattern data 07H 0AH 12H 0AH 07H 00H 00H 00H
