6-42 ● Transmission Sequences
ESC
Header
81H
Item No. Type
Hundred
thousands
position
Ten
thousands
position
thousands
position
Hundreds
position
Tens
position
Unit
position
Code of type
In progress Unit
ASCII 30 31
Update setting range
Set item Update setting range
In progress 000000 to 999998
Unit 000001 to 999999
(3) Direction, External signal count, Reset signal
ESC Header 82H Item No. Type 0/1
Direction (0: up, 1: down)
External signal count (0: Disable, 1: Enable)
Reset signal (0:Signal1, 1:Signal2)
Code of type
Direction External signal count Reset signal
ASCII 30 31 32
ASCII is hexadecimal number.
ASCII is hexadecimal number.
(4) Increment
ESC
Header
83H
Item No.
Tens
position
Unit
position
Increment setting range
Set item Increment setting range
Increment 01 to 99
