Honda BF40D - Page 216

10-27
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
16) Clean the cylinder block/crankcase mating surfaces
thoroughly using the degreasing cleaning solvent.
17) Apply liquid gasket (ThreeBond
®
#1141C or equivalent) to
indicated area of the crankcase.
18) Install the crankcase on the cylinder block.
[1]
CRANKCASE
[1]
LIQUID GASKET
APPLICATION
AREA
216
