Honda BF40D - Electrical Equipment; Layout Drawing

18-1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1. LAYOUT DRAWING.......................... 18-1
2. STARTER MOTOR ............................ 18-4
3. STARTER CABLE/STARTER
SOLENOID/MAIN RELAY/
NEUTRAL SWITCH ......................... 18-15
4. FUSE BOX ....................................... 18-18
5. ELECTRIC PART COVER/ECM ....... 18-19
6. ELECTRIC PART CASE ................... 18-20
7. POWER TILT RELAY/POWER
TILT SWITCH [POWER TRIM/
TILT TYPE ONLY]............................ 18-21
8. IGNITION COIL/
REGULATOR/RECTIFIER................ 18-23
9. METER/METER HARNESS A......... 18-27
1. LAYOUT DRAWING
[5]
REGULATOR/RECTIFIER
[7]
POWER TILT RELAY
(POWER TRIM/TILT TYPE ONLY)
[6]
POWER TILT SWITCH
(POWER TRIM/TILT TYPE ONLY)
[1]
PULSER ROTOR
[2]
PULSER COIL
[3]
IGNITION COIL (3)
[4]
SPARK PLUG
CAP (3)
18. ELECTRICAL EQUIPMENT
