Honda BF40D - Electric Part Cover;Ecm

18-19
5. ELECTRIC PART COVER/ECM
• REMOVAL/INSTALLATION
Remove the engine cover (P. 4-2).
Install and route the connectors and harnesses in the proper positions (P. 2-63).
[4]
ECM
[3]
ECM BRACKET
6 x 14
[1]
CONNECTOR BRACKET C
[2]
ELECTRIC PART COVER
5 N
.
m (0.5 kgf
.
m,
3.7 lbf
.
ft)
6 x 20 (2)
696
