20) Connect the power tilt motor 2P connector.
Lift up the outboard motor with a hoist and install it on the
boat.
21) When the outboard motor is locked with a tilt stopper,
move the stopper to the "FREE" position.
Lower the outboard motor to the lowermost position by
operating the power tilt switch.
22) Install the following parts.
- ECM (P. 7-19)
- Electric part cover (P. 18-19)
- Engine cover (P. 4-2)
[1]
POWER TILT MOTOR
2P CONNECTOR
