18-5
b. DISASSEMBLY
1) Remove the two through bolts, and remove the rear
bracket and the rear washer.
[2]
THROUGH
BOLT (2)
[1]
REAR BRACKET
2) Remove the 8 mm hex nut, and remove the 8 mm spring
washer and the 8 mm washer.
[2]
8 mm
HEX NUT
[3]
REAR WASHER
[1]
8 mm WASHER
[3]
8 mm SPRING
WASHER
3) Remove the two 4 mm screws, and remove the brush
holder.
4) Remove the M-bushing from the rear bracket.
[4]
BRUSH
HOLDER
[2]
REAR
BRACKET
[1]
4 mm
SCREW (2)
[3]
M-BUSHING
668
