5.L SP
ADVAN CER 5.5 BATT ERY
a . In sp ecti ng the Sp ar k A dvance r
I 1 l The check of the spark advancer operation ma y
be performed on the engine with a timing light.
When checking a removed unit, spread the
counterweig hts apart wi th the fingers and if the
weights return to the normal po s iti on smooth ly
when released, the advancer is ope ra ting satis-
factorily. (F ig. 5 -1 5)
121 Check for broken spring.
5.5 BATTERY
1. C O NST RUC TIO N
The battery stores the electric i ty pr oduced by the
generator for use as a source of power for the
safety it ems such as the turn signal lamps. At present,
all battery used for small type vehicles are of a lead
storage type incl osed in a plastic case. T he
construction and the name of the component parts
are shown in Fig 5.17 (F ig . 5 -1 6, 5- 17)
2. RATI NG
Type
Voltage
Capacity
Normal charging rote
Specific gravity of
el ect ro l yte
!when fully charged!
MBC 1- 6
6V
2AH ( 1 0 hour rate)
0.2A
1 ,260- 1 ,280
at 20°CI68°Fl
C50W
C 65M c;:.CE :SC C:S:
O pe ns 2. SOO{ r. p.m)=:l 50 : · :: ·;....-
15' .... 4. 000{ r.p.m ) ;o "::C
g "t-- ~~ -t------------
~ 20+- -f --+- -- -A
i !Sj-- ----1----+--1 '- f- ---- -
14 - - f------ -1
12i- -f---
!Oi--- f----+ --l
1.000
En iine r evolution (r .p. m)
Fi gu re 5- 14. Spark advance performance chart
Figure 5- I 5. Inspecting spark advancer
fig u re 5-16. Battery
e el ec trode pl ate
Fig ure 5- 17. Co stru ct i on of batte ry
73
