CLSS Gateway - Installation and Users’ Manual | P/N:LS10248-000HW-E | REV. F | FEB/11/2022 83
System Troubles Register Map Modbus Communications
460027
0 REMOTE DISPLAY 17 TROUBLE 8 REMOTE DISPLAY 21 TROUBLE
1 REMOTE DISPLAY 17 NO ANSWER 9 REMOTE DISPLAY 21 NO ANSWER
2 REMOTE DISPLAY 18 TROUBLE 10 REMOTE DISPLAY 22 TROUBLE
3 REMOTE DISPLAY 18 NO ANSWER 11 REMOTE DISPLAY 22 NO ANSWER
4 REMOTE DISPLAY 19 TROUBLE 12 REMOTE DISPLAY 23 TROUBLE
5 REMOTE DISPLAY 19 NO ANSWER 13 REMOTE DISPLAY 23 NO ANSWER
6 REMOTE DISPLAY 20 TROUBLE 14 REMOTE DISPLAY 24 TROUBLE
7 REMOTE DISPLAY 20 NO ANSWER 15 REMOTE DISPLAY 24 NO ANSWER
460028
0 REMOTE DISPLAY 25 TROUBLE 8 REMOTE DISPLAY 29 TROUBLE
1 REMOTE DISPLAY 25 NO ANSWER 9 REMOTE DISPLAY 29 NO ANSWER
2 REMOTE DISPLAY 26 TROUBLE 10 REMOTE DISPLAY 30 TROUBLE
3 REMOTE DISPLAY 26 NO ANSWER 11 REMOTE DISPLAY 30 NO ANSWER
4 REMOTE DISPLAY 27 TROUBLE 12 REMOTE DISPLAY 31 TROUBLE
5 REMOTE DISPLAY 27 NO ANSWER 13 REMOTE DISPLAY 31 NO ANSWER
6 REMOTE DISPLAY 28 TROUBLE 14 REMOTE DISPLAY 32 TROUBLE
7 REMOTE DISPLAY 28 NO ANSWER 15 REMOTE DISPLAY 32 NO ANSWER
460029
0 SYSTEM INITIALIZATION 8 Reserved
1 POWER SUPPLY COMM FAILURE 9 Reserved
2 Reserved 10 Reserved
3 Reserved 11 Reserved
4 Reserved 12 Reserved
5 Reserved 13 Reserved
6 Reserved 14 Reserved
7 Reserved 15 Reserved
460030
0 Reserved 8 Reserved
1 Reserved 9 Reserved
2 Reserved 10 Reserved
3 Reserved 11 Reserved
4 Reserved 12 Reserved
5 Reserved 13 Reserved
6 Reserved 14 Reserved
7 Reserved 15 Reserved
Table 7.33: System Troubles Register Map (Continued)
To Next Page
