CLSS Gateway - Installation and Users’ Manual | P/N:LS10248-000HW-E | REV. F | FEB/11/2022 84
System Troubles Register Map Modbus Communications
460031
0 Reserved 8 Reserved
1 Reserved 9 Reserved
2 Reserved 10 Reserved
3 Reserved 11 Reserved
4 Reserved 12 Reserved
5 Reserved 13 Reserved
6 Reserved 14 Reserved
7 Reserved 15 Reserved
460032
0 Reserved 8 NO POWER SUPPLY INST
1 Reserved 9 LOOP 1-2 COMM FAILURE
2 LINK PROTECTOR PRIMARY STATUS 10 LOOP 3-4 COMM FAILURE
3
LINK PROTECTOR SECONDARY
STATUS
11 LOOP 5-6 COMM FAILURE
4 LINK PROTECTOR NOT PRESENT 12 LOOP 7-8 COMM FAILURE
5
EVENT BUFFER 80% FULL / HISTORY
80% FULL
13 LOOP 9-10 COMM FAILURE
6 EBI STATUS 14 TEST PROGRAM UPDATE
7 SOFTWARE MISMATCH 15 Reserved
460033
0 LOOP CONTINUITY TEST FAIL LOOP 1 8 LOOP CONTINUITY TEST FAIL LOOP 9
1 LOOP CONTINUITY TEST FAIL LOOP 2 9 LOOP CONTINUITY TEST FAIL LOOP 10
2 LOOP CONTINUITY TEST FAIL LOOP 3 10 UNPROGRAMMED DEVICE ON LOOP 1
3 LOOP CONTINUITY TEST FAIL LOOP 4 11 UNPROGRAMMED DEVICE ON LOOP 2
4 LOOP CONTINUITY TEST FAIL LOOP 5 12 UNPROGRAMMED DEVICE ON LOOP 3
5 LOOP CONTINUITY TEST FAIL LOOP 6 13 UNPROGRAMMED DEVICE ON LOOP 4
6 LOOP CONTINUITY TEST FAIL LOOP 7 14 UNPROGRAMMED DEVICE ON LOOP 5
7 LOOP CONTINUITY TEST FAIL LOOP 8 15 UNPROGRAMMED DEVICE ON LOOP 6
460034
0
UNPROGRAMMED DEVICE ON LOOP
7
8 IR ENABLED ON LOOP 5
1
UNPROGRAMMED DEVICE ON LOOP
8
9 IR ENABLED ON LOOP 6
2
UNPROGRAMMED DEVICE ON LOOP
9
10 IR ENABLED ON LOOP 7
3
UNPROGRAMMED DEVICE ON LOOP
10
11 IR ENABLED ON LOOP 8
4 IR ENABLED ON LOOP 1 12 IR ENABLED ON LOOP 9
5 IR ENABLED ON LOOP 2 13 IR ENABLED ON LOOP 10
6 IR ENABLED ON LOOP 3 14
TRANSMIT/RECIEVE ERROR ABOVE
LIMIT ON LOOP 1
7 IR ENABLED ON LOOP 4 15
TRANSMIT/RECIEVE ERROR ABOVE
LIMIT ON LOOP 2
Table 7.33: System Troubles Register Map (Continued)
