CLSS Gateway - Installation and Users’ Manual | P/N:LS10248-000HW-E | REV. F | FEB/11/2022 85
System Troubles Register Map Modbus Communications
460035
0
TRANSMIT/RECIEVE ERROR ABOVE
LIMIT ON LOOP 3
8 TOO MANY DEVICES ON LOOP 1
1
TRANSMIT/RECIEVE ERROR ABOVE
LIMIT ON LOOP 4
9 TOO MANY DEVICES ON LOOP 2
2
TRANSMIT/RECIEVE ERROR ABOVE
LIMIT ON LOOP 5
10 TOO MANY DEVICES ON LOOP 3
3
TRANSMIT/RECIEVE ERROR ABOVE
LIMIT ON LOOP 6
11 TOO MANY DEVICES ON LOOP 4
4
TRANSMIT/RECIEVE ERROR ABOVE
LIMIT ON LOOP 7
12 TOO MANY DEVICES ON LOOP 5
5
TRANSMIT/RECIEVE ERROR ABOVE
LIMIT ON LOOP 8
13 TOO MANY DEVICES ON LOOP 6
6
TRANSMIT/RECIEVE ERROR ABOVE
LIMIT ON LOOP 9
14 TOO MANY DEVICES ON LOOP 7
7
TRANSMIT/RECIEVE ERROR ABOVE
LIMIT ON LOOP 10
15 TOO MANY DEVICES ON LOOP 8
460036
0 TOO MANY DEVICES ON LOOP 9 8 MISMATCHED LOOP TYPE ON LOOP 7
1 TOO MANY DEVICES ON LOOP 10 9 MISMATCHED LOOP TYPE ON LOOP 8
2 MISMATCHED LOOP TYPE ON LOOP 1 10 MISMATCHED LOOP TYPE ON LOOP 9
3 MISMATCHED LOOP TYPE ON LOOP 2 11 MISMATCHED LOOP TYPE ON LOOP 10
4 MISMATCHED LOOP TYPE ON LOOP 3 12 Ground Fault Port A
5 MISMATCHED LOOP TYPE ON LOOP 4 13 Ground Fault Port B
6 MISMATCHED LOOP TYPE ON LOOP 5 14 Amplifier Trouble
7 MISMATCHED LOOP TYPE ON LOOP 6 15 AUXIN Trouble
460037
0 DIGIN Trouble 8 ANALOG OUTPUT A TROUBLE
1 FFT TROUBLE 9 ANALOG OUTPUT B TROUBLE
2 REMOTE MIC Trouble 10 ANALOG OUTPUT C TROUBLE
3 DAP Port A Failure 11 ANALOG OUTPUT D TROUBLE
4 DAP Port B Failure 12 Reserved
5
DAL No Answer / DAL DEVICE NO
ANSWER
13 Reserved
6 LOCAL MIC TROUBLE 14 AMPLIFIER LIMIT
7 LOCAL PHONE TROUBLE 15 AMPLIFIER SUPERVISION
Table 7.33: System Troubles Register Map (Continued)
