CLSS Gateway - Installation and Users’ Manual | P/N:LS10248-000HW-E | REV. F | FEB/11/2022 86
System Troubles Register Map Modbus Communications
460038
0 DAL ADDRESS CONFLICT 8 MAPPING IN PROGRESS LOOP 7
1 DEVICE SERVICING REQUIRED 9 MAPPING IN PROGRESS LOOP 8
2 MAPPING IN PROGRESS LOOP 1 10 MAPPING IN PROGRESS LOOP 9
3 MAPPING IN PROGRESS LOOP 2 11 MAPPING IN PROGRESS LOOP 10
4 MAPPING IN PROGRESS LOOP 3 12 DATABASE CORRUPTED
5 MAPPING IN PROGRESS LOOP 4 13 AUDIO LIBRARY CORRUPTED
6 MAPPING IN PROGRESS LOOP 5 14 DATABASE INCOMPATIBLE
7 MAPPING IN PROGRESS LOOP 6 15 AUDIO LIBRARY INCOMPATIBLE
460039
0 DAL DOWNLOAD IN PROGRESS 8 PRIMARY AMP 1 TROUBLE
1 FIRE VOICE TROUBLE 9 PRIMARY AMP 2 TROUBLE
2 FIRE VOICE NO ANSWER 10 PRIMARY AMP 3 TROUBLE
3 PHONE CHANNEL LIMIT EXCEEDED 11 PRIMARY AMP 4 TROUBLE
4 NCM SMIFFER MODE ACTIVE 12 BACKUP AMP 1 TROUBLE
5
LOCAL CONNECTION LIMIT
EXCEEDED
13 BACKUP AMP 2 TROUBLE
6 HARDWARE MISMATCH 14 BACKUP AMP 3 TROUBLE
7 Reserved 15 BACKUP AMP 4 TROUBLE
460040
0 DSBUS 1 COMMFAIL 8 PRIMARY AMP 2 LIMIT
1 DSBUS 2 COMMFAIL 9 PRIMARY AMP 3 LIMIT
2 DSBUS 3 COMMFAIL 10 PRIMARY AMP 4 LIMIT
3 DSBUS 4 COMMFAIL 11 BACKUP AMP 1 LIMIT
4 AA TROUBLE BUS FAIL 12 BACKUP AMP 2 LIMIT
5
NFN PAGING CHANNEL LIMIT
EXCEEDED
13 BACKUP AMP 3 LIMIT
6 BACKUP AMP LIMIT 14 BACKUP AMP 4 LIMIT
7 PRIMARY AMP 1 LIMIT 15 PRIMARY AMP 1 OVERCURRENT
460041
0 PRIMARY AMP 2 OVERCURRENT 8 PRIMARY AMP 2 TRIP
1 PRIMARY AMP 3 OVERCURRENT 9 PRIMARY AMP 3 TRIP
2 PRIMARY AMP 4 OVERCURRENT 10 PRIMARY AMP 4 TRIP
3 BACKUP AMP 1 OVERCURRENT 11 BACKUP AMP 1 TRIP
4 BACKUP AMP 2 OVERCURRENT 12 BACKUP AMP 2 TRIP
5 BACKUP AMP 3 OVERCURRENT 13 BACKUP AMP 3 TRIP
6 BACKUP AMP 4 OVERCURRENT 14 BACKUP AMP 4 TRIP
7 PRIMARY AMP 1 TRIP 15 DSBUS 1 AC FAIL
460042
0 DSBUS 2 AC FAIL 8 DSBUS 2 LOW BATT
1 DSBUS 3 AC FAIL 9 DSBUS 3 LOW BATT
2 DSBUS 4 AC FAIL 10 DSBUS 4 LOW BATT
3 DSBUS 1 HIGH BATT 11 DSBUS 1 SELF TEST FAIL
4 DSBUS 2 HIGH BATT 12 DSBUS 2 SELF TEST FAIL
5 DSBUS 3 HIGH BATT 13 DSBUS 3 SELF TEST FAIL
6 DSBUS 4 HIGH BATT 14 DSBUS 4 SELF TEST FAIL
7 DSBUS 1 LOW BATT 15 PRIMARY AMP 1 FAIL
Table 7.33: System Troubles Register Map (Continued)
