CLSS Gateway - Installation and Users’ Manual | P/N:LS10248-000HW-E | REV. F | FEB/11/2022 87
System Troubles Register Map Modbus Communications
460043
0 PRIMARY AMP 2 FAIL 8 BACKUP AMP 1 NOT INSTALLED
1 PRIMARY AMP 3 FAIL 9 BACKUP AMP 2 NOT INSTALLED
2 PRIMARY AMP 4 FAIL 10 BACKUP AMP 3 NOT INSTALLED
3 BACKUP AMP 1 FAIL 11 BACKUP AMP 4 NOT INSTALLED
4 BACKUP AMP 2 FAIL 12 MODBUS COMMUNICATIONS FAULT
5 BACKUP AMP 3 FAIL 13 VESDANET TROUBLE
6 BACKUP AMP 4 FAIL 14 Reserved
7 BACKUP AMP NOT INSTALLED 15 DOOR INTERLOCK FAULT
460044
0 ANNUN 01 TYPE MISMATCH 8 ANNUN 09 TYPE MISMATCH
1 ANNUN 02 TYPE MISMATCH 9 ANNUN 10 TYPE MISMATCH
2 ANNUN 03 TYPE MISMATCH 10 ANNUN 11 TYPE MISMATCH
3 ANNUN 04 TYPE MISMATCH 11 ANNUN 12 TYPE MISMATCH
4 ANNUN 05 TYPE MISMATCH 12 ANNUN 13 TYPE MISMATCH
5 ANNUN 06 TYPE MISMATCH 13 ANNUN14 TYPE MISMATCH
6 ANNUN 07 TYPE MISMATCH 14 ANNUN 15 TYPE MISMATCH
7 ANNUN 08 TYPE MISMATCH 15 ANNUN 16 TYPE MISMATCH
460045
0 ANNUN 17 TYPE MISMATCH 8 ANNUN 25 TYPE MISMATCH
1 ANNUN 18 TYPE MISMATCH 9 ANNUN 26 TYPE MISMATCH
2 ANNUN 19 TYPE MISMATCH 10 ANNUN 27 TYPE MISMATCH
3 ANNUN 20 TYPE MISMATCH 11 ANNUN 28 TYPE MISMATCH
4 ANNUN 21 TYPE MISMATCH 12 ANNUN 29 TYPE MISMATCH
5 ANNUN 22 TYPE MISMATCH 13 ANNUN 30 TYPE MISMATCH
6 ANNUN 23 TYPE MISMATCH 14 ANNUN 31 TYPE MISMATCH
7 ANNUN 24 TYPE MISMATCH 15 ANNUN 32 TYPE MISMATCH
460046
0 DISPLAY COMM LOSS 8 LOOP CARD 1 COMM LOSS
1 ALARM DEVICES DISABLED 9 LOOP CARD 2 COMM LOSS
2 SMOKE CONTROL DISABLED 10 LOOP CARD 3 COMM LOSS
3 PANEL HAS REBOOTED 11 LOOP CARD 4 COMM LOSS
4 ZONES DISABLED BY BRIGADE 12 LOOP CARD 5 COMM LOSS
5 ALARM SIGNAL 13 LOOP CARD 6 COMM LOSS
6 KERNEL CORRUPTED 14 LOOP CARD 7 COMM LOSS
7 CHANGE SERVICE TOOL PASSWORD 15 LOOP CARD 8 COMM LOSS
460047
0 LOOP CARD 9 COMM LOSS 8 PMB 4 COMM LOSS
1 LOOP CARD 10 COMM LOSS 9 PMB 5 COMM LOSS
2 CHANGE MASTER USER PASSWORD 10 Recovery Partition Application Active
3 PASSWORD DATABASE CORRUPTED 11 AIO COMM CLASS A TROUBLE
4 Default database. Please program. 12 AC Failure (LSB is PMB address 1-5)
5 PMB 1 COMM LOSS 13 Earth Fault (LSB is PMB address 1-5)
6 PMB 2 COMM LOSS 14
Earth Fault Switch Mismatch (LSB is
PMB address 1-5)
7 PMB 3 COMM LOSS 15 Battery Low (LSB is PMB address 1-5)
Table 7.33: System Troubles Register Map (Continued)
