System Troubles Register Map Modbus Communications
460048
0 Battery High (LSB is PMB address 1-5) 8
AIO Address 5 Comm Loss (LSB is 0 for
router, 1-15 for peripheral)
1
Battery Deep-Discharge (LSB is PMB
address 1-5)
9
AIO Address 6 Comm Loss (LSB is 0 for
router, 1-15 for peripheral)
2 Charger Fail (LSB is PMB address 1-5) 10
AIO Address 7 Comm Loss (LSB is 0 for
router, 1-15 for peripheral)
3
Power Supply Failure (LSB is PMB
address 1-5)
11
AIO Address 8 Comm Loss (LSB is 0 for
router, 1-15 for peripheral)
4
AIO Address 1 Comm Loss (LSB is 0 for
router, 1-15 for peripheral)
12
AIO Address 9 Comm Loss (LSB is 0 for
router, 1-15 for peripheral)
5
AIO Address 2 Comm Loss (LSB is 0 for
router, 1-15 for peripheral)
13
AIO Address 10 Comm Loss (LSB is 0 for
router, 1-15 for peripheral)
6
AIO Address 3 Comm Loss (LSB is 0 for
router, 1-15 for peripheral)
14 Reserved
7
AIO Address 4 Comm Loss (LSB is 0 for
router, 1-15 for peripheral)
15 Reserved
460049
0 POTS Card No Answer / Missing 8 Ethernet 1 No Connectivity
1 POTS Line 1 Failure 9 Ethernet 2 No Connectivity
2 POTS Line 2 Failure 10
CLSS Site Manager Communication
Failure
3 POTS Call (Alarm Routing) Failure 11 Ethernet/Wini Alarm Routing Failure
4 POTS Software Mismatch 12 Cellular Alarm Routing Failure
5 Cellular Card No Answer / Missing 13 Reserved
6 Cellular Card No Connectivity 14 Reserved
7 Wini No Connectivity 15 Reserved
Table 7.33: System Troubles Register Map (Continued)
