MDR 710 – WWL Conveyor | Maintenance Manual | 29349817 41
November 16, 2020
Service and Repair
BF PART NO Description
16 49636006 MDR 710 Finger Guard Between Sections 3” Belt Wxx
22 49636007 MDR 710 Finger Guard Between Sections 3” Belt Wxx
28 49636008 MDR 710 Finger Guard Between Sections 3” Belt Wxx
34 49636009 MDR 710 Finger Guard Between Sections 3” Belt Wxx
40 49636010 MDR 710 Finger Guard Between Sections 3” Belt Wxx
16 49636906 MDR 710 Finger Guard Between Zones 5” Belt Wxx
22 49636907 MDR 710 Finger Guard Between Zones 5” Belt Wxx
28 49636908 MDR 710 Finger Guard Between Zones 5” Belt Wxx
34 49636909 MDR 710 Finger Guard Between Zones 5” Belt Wxx
40 49636910 MDR 710 Finger Guard Between Zones 5” Belt Wxx
16 49636806 MDR 710 Finger Guard Between Sections 5” Belt Wxx
22 49636807 MDR 710 Finger Guard Between Sections 5” Belt Wxx
28 49638808 MDR 710 Finger Guard Between Sections 5” Belt Wxx
34 49636809 MDR 710 Finger Guard Between Sections 5” Belt Wxx
40 49636810 MDR 710 Finger Guard Between Sections 5” Belt Wxx
16 49636101 MDR 710 Finger Guard O-Belt DRV RLR W__
22 49636102 MDR 710 Finger Guard O-Belt DRV RLR W__
28 49636103 MDR 710 Finger Guard O-Belt DRV RLR W__
34 49636104 MDR 710 Finger Guard O-Belt DRV RLR W__
40 49636105 MDR 710 Finger Guard O-Belt DRV RLR W__
Between Roller Gap Filler
QTY. PART NO Description
1 493562__ MDR 710 T – Bar Gap Filler BTW Belts
2 49356600 Bracket, Finger Guard, Frame Abutment
2 Gap Filler Mounting Screw
See Table Filler Clip .75 inch TEE Finger Guard
