40 MDR 710 – WWL Conveyor | Maintenance Manual | 29349817
November 16, 2020
Service and Repair
3” Belt Between Zone Gap Filler Clips
Lenght Part Number
Qty 16”
BF
Qty 22”
BF
Qty 28”
BF
Qty 34”
BF
Qty 40”
BF
2.50 49389905 1
3.00 49389906 2 4 2 2 2
3.25 49389907 4
4.75 49389909 4
6.00 49389910 2
5” Belt Between Zone Filler Clips
Lenght Part Number
Qty 16”
BF
Qty 22”
BF
Qty 28”
BF
Qty 34”
BF
Qty 40”
BF
1.00 49389901 2 2 2 2 2
1.75 49389902 2 4
2.00 49389903 2 1
2.50 49389905 1
3.25 49389907 4
3” and 5” Belt Between Zone Gap Filler
QTY. PART NO Description
1 496364__ MDR 710 H – Bar Gap Filler O-Belt DRV RLR __BF
2 49636600 Mounting Bracket, Finger Guard, Between Rollers
2 20237700 Phillips Flat Head Screw, ¼” – 20 x ¾” Long W/ Nylon Patch
Gap Filler Retrofit Kits
BF PART NO Description
16 49636206 MDR 710 Finger Guard Between Zones 3” Belt Wxx
22 49636207 MDR 710 Finger Guard Between Zones 3” Belt Wxx
28 49636208 MDR 710 Finger Guard Between Zones 3” Belt Wxx
34 49636209 MDR 710 Finger Guard Between Zones 3” Belt Wxx
40 49636210 MDR 710 Finger Guard Between Zones 3” Belt Wxx
