78 MDR 710 – WWL Conveyor | Maintenance Manual | 29349817
November 16, 2020
SEQ QTY PART NO Description
10 1 150001__ WWL ST 60-180FPM DGR STD TRQ RLLR __BF (15 IN CABLE)
150002__ WWL ST 60-180FPM DGR STD TRQ BRK RLLR __BF (15 IN
CABLE)
491076__ 710 MDR WWL STSS W/ BRK STRIP BELT RLR WITH
TRACKING TIRE W__
491076__ RLLR G196 NO GROOVE __BF WITH TRACKING TIRE
491103__ 710 MDR G196AB MDR DGR STRIP BELT WITH TRACKING
TIRE W__
491141__ 710 MDR G196AB MDR DGR STRIP BELT WITH TRACKING
TIRE AND ADH W__
11 6 140002__ ROL G196AB __.00"BF AX7
140061100 ROL G196AB __.00BF AX7 B2006
12 1 150003__ WWL ST 60-180FPM NO GRV STD TRQ RLLR __BF (15 IN
CABLE)
150003555 WWL ST 60-180FPM NO GRV STD TRQ RLLR
55.71(1415MM)BF (15 IN CABLE)
13 3 49105100 WWL POINTS UP 3 PLT AXLE LOCK
14 1 150004__ WWL ST 60-180FPM NO GRV STD TRQ BRK RLLR __BF (15 IN
CABLE)
150005__ WWL HT 60-180FPM DGR HI TRQ RLLR __BF (15 IN CABLE)
150007__ WWL HT 60-180FPM NO GRV HI TRQ RLLR __BF (15 IN
CABLE)
150009160 WWL HT 100-300FPM DGR HI TRQ HI SPD RLLR 16BF (15 IN
CABLE)
15 12 29156900 TIRE URETHANE TRACKNG 1.9RLR 1.00"WIDE 1/32"THK
16 6 490223__ 710 MDR STRIP BELT __" ZN
17 2 23325800 WWL CS1001 SZC CONTROL CARD #CS10010200 VERSION
1.2D7.2
18 2 49091900 REFLECTOR MICROCUBE SICK #7123377
19 2 23386800 PHOTO EYE 4-PIN WAGO CONNECTOR PNP DARK ACTUATE
W/ALARM OUTPUT PNP SICK #1051589 (MODEL ZL2-
F2400S07)
20 1 23325800 WWL CS1001 SZC CONTROL CARD #CS10010200 VERSION
1.2D7.2
21 1 49037600 710 MDR BnR MODULE W/BRKT
22 2 29003000 LABEL PRODUCT TRAVEL
23 2 29042700 LABEL CEMA #CHR930004 SHORT (1.75 X 5.00)
24 2 49059000 MDR 710 PIVOT PF BRACKET DOWNSTREAM
25 2 49059100 MDR 710 PIVOT PF BRACKET UPSTREAM
To Next Page
