MDR 710 – WWL Conveyor | Maintenance Manual | 29349817 79
November 16, 2020
SEQ QTY PART NO Description
26 22 220003 BOLT CAR .375-16 X .750 SHORT SQ NECK
27 30 221055 NUT FLANGE .375-16
28 8 220018 BOLT HEX .375-16 X .750
29 2 490382 710 MDR BELT ZN SLIDER PAN "BF
30 2 305227 O-BELT .25 X 9.437 LG 83A
31 4 49042900 MDR 710 GROUND STRAP .5 X 12"LG W/.3125 TERM.
32 13 20061500 BOLT HEX FLG .313-18 X .750
33 2 49042900 MDR 710 GROUND STRAP .5 X 12"LG W/.3125 TERM.
34 1 165476 PUSH MOUNT CLIP PANDUIT #HCMP06C-12-M20
35 1 20046000 RIVET NYLON SNAP-LOCK .295-.335 GRIP (RICHCO# SR-
4100B) REPLACES 44009600
36 1 23276600 IDEAL MODULE FOR MDR710 UNIVERSAL MIXED I/O
VERSION E0 OR GREATER B&R #X67UM4389
37 1 49037600 710 MDR ELEC B&R INTELLIGRATED IDEAL MODULE
PHANTOM ASSY WITH CABLES
49019200 710 MDR ELEC HB510 POWER CABLE 8"LG
38 1 44003200 FUSE 3 AMP ATC VIOLET ATC-3
To Next Page
