MDR 710 – WWL Conveyor | Maintenance Manual | 29349817 85
November 16, 2020
SEQ QTY PART NO Description
1 4 49060502 MDR 710 CHAN PF/NO 24" LG 2-ZN OPP
3 4 20054600 GROMMET 1.125"OD X .625"ID FOR .875 DIA HOLE
4 2 490388__ 710 MDR EXTRUDED WIREWAY X-OVER __BF
5 4 490000__ MDR SPDR STAMPED __"BF
7 3 20057700 BOLT CAR TRUSS HD SPCL .313-18 X .625
8 2 140066__ ROL G196AB __.00"BF MDR DGR AX7 B2006
9 2 150001__ WWL ST 60-180FPM DGR STD TRQ RLLR __BF (15 IN CABLE)
150005__ WWL HT 60-180FPM DGR HI TRQ RLLR __BF (15 IN CABLE)
150002__ WWL ST 60-180FPM DGR STD TRQ BRK RLLR __BF (15 IN
CABLE)
491078__ 710 MDR WWL STSS W/ BRK DENS PAT BELT RLR WITH
TRACKING TIRE W__
491079__ 710 MDR G196AB MDR DGR DENSE PATT BELT WITH
TRACKING TIRE AND ADH W__
491142__ 710 MDR G196AB MDR DGR DENSE PATT BELT WITH
TRACKING TIRE W__
10 8 140061__ ROL G196AB __.00BF AX7 B2006
11 1 150003__ WWL ST 60-180FPM NO GRV STD TRQ RLLR __BF (15 IN
CABLE)
150007__ WWL HT 60-180FPM NO GRV HI TRQ RLLR __BF (15 IN
CABLE)
150009160 WWL HT 100-300FPM DGR HI TRQ HI SPD RLLR 16BF (15 IN
CABLE)
12 2 49091900 REFLECTOR MICROCUBE SICK #7123377
13 2 150004__ WWL ST 60-180FPM NO GRV STD TRQ BRK RLLR __BF (15 IN
CABLE)
491078__ WWL ST-60-180FPM NGR STD TRQ RLLR __BF 15"CABLE
WITH TRACKING TIRE
14 4 23325800 WWL CS1001 SZC CONTROL CARD #CS10010200 VERSION
1.2D7.2
15 2 23386800 PHOTO EYE 4-PIN WAGO CONNECTOR PNP DARK ACTUATE
W/ALARM OUTPUT PNP SICK #1051589 (MODEL ZL2-
F2400S07)
16 1 49037600 710 MDR ELEC B&R INTELLIGRATED IDEAL MODULE
PHANTOM ASSY WITH CABLES
19 4 490382__ 710 MDR BELT ZN SLIDER PAN __"BF
22 2 49059000 MDR 710 PIVOT PF BRACKET DOWNSTREAM
23 2 49059100 MDR 710 PIVOT PF BRACKET UPSTREAM
25 6 49042900 MDR 710 GROUND STRAP .5 X 12"LG W/.3125 TERM.
To Next Page
