86 MDR 710 – WWL Conveyor | Maintenance Manual | 29349817
November 16, 2020
SEQ QTY PART NO Description
27 4 305227 O-BELT .25 X 9.437 LG 83A
28 4 49105100 WWL POINTS UP 3 PLT AXLE LOCK
29 12 29406800 TIRE URETHANE TRACKING 1.9RLR 1.00"WD 1/16"THK
5.594LG 83A
30 6 49048624 MDR 710 BELT FLEXAM EM 8/2 0+P8 BLUE AS 5"W 24"ZN
31 1 165476 PUSH MOUNT CLIP PANDUIT #HCMP06C-12-M20
32 1 23276600 IDEAL MODULE FOR MDR710 UNIVERSAL MIXED I/O
VERSION E0 OR GREATER B&R #X67UM4389
33 1 23295400 HB-510P-IT7 PNP MDR HIGH TORQUE CONTROL CARD ZPA
ITOH DENKI (WAS HB510P-IT3, 4, 5 & 6)
34 1 23295500 HB-510BP-IT7 PNP MDR HIGH TORQUE CONTROL CARD ZPA
WITH BRAKE ITOH DENKI (WAS HB510BP-IT3, 4, 5 & 6)
35 1 44003200 FUSE 3 AMP ATC VIOLET ATC-3
36 1 49037600 710 MDR ELEC B&R INTELLIGRATED IDEAL MODULE
PHANTOM ASSY WITH CABLES
37 1 49019200 710 MDR ELEC HB510 POWER CABLE 8"LG
38 1 20046000 RIVET NYLON SNAP-LOCK .295-.335 GRIP (RICHCO# SR-
4100B) REPLACES 44009600
To Next Page
