22–3
Detect and Notify Mode (Monitor the External
Trigger) – The external I/O pin used in the default
activation mode is monitored during the inactive
laser cycles. An <SI> is transmitted when the I/O
is active and an <SO> when it is inactive. Once
the scanning activation cycle is started, the
external I/O monitoring status is maintained until
the scanning cycle is terminated regardless of the
actual I/O level.
Continuous Blinky Mode
Continuous Blinky Mode – The scanner will
continuously blink on and off,
cycle on and off for all normal scanner operations.
If a bar code is scanned and transmitted, the same
symbol timeout is maintained throughout the cycle
preventing additional scans of the same bar code
when the scanner is in default mode.
Sleep Mode
~ Sleep Mode – A power saving mode that can
be configured to occur in 1-second increments.
Use this code with a code byte sequence
(on page 16–
1) that represents the desired
increment.
