MS9524 and MS9544
VoyagerPDF
®
Series
³ 1 0 0 0 1 0
* Enable PDF
³ 1 0 0 0 0 0
Disable PDF
³ 1 1 5 0 1 0
* Enable Audible Indicator
³ 1 1 5 0 0 0
Disable Audible Indicator
PDF CodeGate Status
³ 1 1 8 7 1 6
Enable PDF CodeGate in Stand
³ 1 1 8 7 0 6
* Disable PDF CodeGate in Stand
³ 1 1 8 7 1 4
Enable PDF CodeGate Out of Stand
³ 1 1 8 7 0 4
* Disable PDF CodeGate Out of Stand
MicroPDF and Composite Code Handling
³ 1 0 0 4 1 7
Enable MicroPDF – Allows composite
symbologies to be scanned (PDF 417 is enabled
by default).
³ 1 0 0 4 0 7
* Disable MicroPDF
³ 1 1 5 0 0 7
* Enabe GS1 DataBar 2D Linkage – T
ransmits the
1D GS1 DataBar without scanning the 2D portion.
