Honeywell Minitrend QX User Manual

43-TV-25-30 Iss.6 GLO Aug 07 UK 105
Calibration Input Ranges
This table shows which input range is used for each input type.
Table 4.7 : Calibration Input range table
Input Type Input Range
K Type TC 50mV
R Type TC 25mV
S Type TC 25mV
B Type TC 10mV
J Type TC 50mV
T Type TC 25mV
E Type TC 100mV
N Type TC 50mV
C (W5) Type TC 50mV
G (W) Type TC 50mV
Chrome Copel 50mV
L Type TC 50mV
M Type TC 50mV
P (Platinel) 100mV
D Type TC 50mV
PT100 RTD 100mV
PT200 RTD 250mV
PT500 RTD 500mV
PT1000 RTD 1000mV
Nickel 100 100mV
Nickel 120 100mV
Cu10 50mV
Cu53 50mV
200 Ohms 50mV
500 Ohms 100mV
1000 Ohms 250mV
4000 Ohms 1000mV
0-20mA 250mV
4-20mA 250mV
