Panel Mounting Clamp Installation
The Minitrend QX, Multitrend SX and the eZtrend QXe recorders slide into the panel
cut-out and are held in place by two (or four) panel clamps. The panel clamps should be fit-
ted on diagonally opposite sides of the unit and tightened against the rear of the panel using
two fixing screws.
The mounting clamp assembly and fitting instructions differ slightly for the two recorders.
Minitrend QX and eZtrend QXe
1. Insert the panel gasket onto the recorder so it goes between the back of the
recorder bezel and the panel. From the front panel, place unit in the panel and
push through the panel.
2. To loosen each clamp, unscrew the long screw to accommodate the panel
thickness.
3. From behind the panel, the orientation of the clamp should be with the screw
head towards the rear of the unit. See .
4. Take the first clamp and locate the two lugs on the clamp into the slots on the
unit. See .
5. Take the second clamp and do the same but in the diagonal position to the
opposite side. See Figure 2.3 on page 8.
6. Tighten the screw using a flat blade screwdriver and the clamp will secure
against the panel.
Multitrend SX
1. Insert the panel gasket onto the recorder so it goes between the back of the
recorder bezel and the panel. From the front panel, place unit in the panel and
push through the panel.
2. To loosen each clamp, unscrew the long screw to accommodate the panel
thickness.
3. From behind the panel, the orientation of the clamp should be with the screw
head towards the rear of the unit. See Figure 2.2 on page 7.
4. Position the circular mounting boss in the hole on one side of the case with the
lip of the boss inside the case. Ensure the front of the clamp is up against the
panel.
5. Fix the second clamp on the opposite side of the unit. See Figure 2.4 on
page 15.
6. Tighten the screw using a flat blade screwdriver and the clamp will secure
against the panel.
CAUTION
CONTROL UNIT DAMAGE
Do not over tighten mounting clamp screws.
Minitrend QX
and eZtrend QXe torque setting should be 0.5 - 0.75Nm/4.4 - 6.6lbf-in
Multitrend SX torque setting should be 0.5 - 0.70Nm/4.4 - 6.2lbf-in
Failure to comply with these instructions may result in product damage
